Starlink Replacement SPX Cable – 5m (16.4ft) for Gen 2 Terminal

Description

Description

The Starlink Replacement SPX Cable – 5m (16.4ft) is a high-quality, compact replacement cable designed for the Starlink Gen 2 Standard Terminal. Ideal for short rooftop, wall, or shed-mounted installs, this cable offers superior electrical performance compared to factory Starlink cables, without excess length to manage.

Made using 24AWG stranded copper conductors, this cable significantly reduces voltage drop compared to the 26AWG used in most genuine and generic cables. The result is better power delivery, especially in DC-powered or off-grid systems where every volt counts.

Shielded with foil and a drain wire, and jacketed in CMX-rated outdoor UV-stable insulation, this cable is built to handle Australia's harsh climate. It comes pre-terminated with a Starlink-compatible IP67 waterproof plug at the terminal end, and a standard RJ45 at the other.

⚠️ Only compatible with Starlink Gen 2 Standard Terminals. Not suitable for Gen 3, Mini, High Performance, or Gen 1 models.

Key Features

✅ 24AWG Stranded Copper – Superior to 26AWG

Thicker copper core handles more current with less resistance. Ideal for short runs where maximum efficiency is still critical.

✅ Shielded and CMX-Rated for Outdoors

UV-stable CMX-rated jacket with foil shielding and drain wire—perfect for external wall mounts, sheds, and short rooftop runs.

✅ Factory-Style Starlink Gen 2 Connector

Includes correct IP67 Starlink Gen 2 waterproof plug for a secure, weatherproof connection—no modifications needed.

✅ Minimal Length, Max Durability

No unnecessary bulk—just 5 metres of high-grade cable for short and tidy installations.

Specifications

• Length: 5 metres (16.4 feet)

• Cable Type: Cat5e FTP (Foil Shielded Twisted Pair)

• Conductor: 24AWG stranded bare copper

• Jacket Rating: CMX Outdoor UV-Stable

• Shielding: Foil with drain wire

• Connector A: Starlink Gen 2 IP67 waterproof plug

• Connector B: Standard RJ45

• Operating Temp: Up to 75°C

• Compatibility: Starlink Gen 2 Standard Terminal only

Installation Overview

1. Power Off First – Disconnect all power sources before removing or installing the cable.

2. Detach Old Cable – Remove existing factory cable from both terminal and router/power injector.

3. Connect New Cable – Push the IP67 connector firmly into the Starlink port until it clicks.

4. Route Neatly – Avoid sharp bends and high-friction contact points.

5. Reconnect Power – Restore system power and verify signal and voltage.

Important Notes

⚠️ Not Compatible with Gen 3, Mini, High Performance, or Gen 1 terminals – This is a Gen 2-only solution.
⚠️ Do Not Use RJ45 Extension Cables – This cable includes the correct waterproof plug for Gen 2.
⚠️ Power Connection Sequence Matters – Ensure your power injector or supply is connected before powering the terminal.

Ideal Use Cases

✅ Wall-mounted or close-range rooftop Starlink setups
✅ Compact caravan or vehicle installations
✅ Short-run replacement for damaged Gen 2 factory cable
✅ Systems using StarPower or 3rd-party DC injectors
✅ Installations in high-UV or harsh weather environments

Clean, Efficient, Built to Last

Don’t settle for fragile factory cables or cheap generics. The 5m SpaceTek SPX Cable gives you better performance in less space, with rugged materials and correct Starlink Gen 2 compatibility built-in. Whether you're mounting on a shed, vehicle, or external wall, it's the smart choice for tidy and efficient Starlink installs.

Need something longer? Explore our 10m and 23m versions for flexible installation options.
